PrimeTest 100 PAT Tester Front
344A910

PrimeTest 100

PAT Testers

Handheld unit for testing earth continuity, insulation resistance and substitute leakage with measured test result values

> Simple-to-use push button operation
> Easy-to-read display with LCD display – shows test results and pass/fail indication
> Accurate and reliable earth continuity testing


More about the PrimeTest 100 PAT tester

A highly useful, functional and diverse tool, the PrimeTest 100 has three operational modes and is an easy-to-use, comprehensive unit.

Simply push the relevant button to run through the pre-programmed test sequences for either Class I PAT test, Class II PAT test or IEC Lead test. Connect the PrimeTest 100 to a power outlet and it will automatically check the socket wiring and mains voltage.

Its large digital display shows test result values, as well as a PASS or FAIL indication. Battery powered, it’ll help you work quicker and more efficiently.

Unlock extra features with our free and easy-to-use mobile app, PATMobile. Available for use on both Android and iOS devices, the handy app works with the PrimeTest 100 to enable the digital input and storage of test records alongside barcode scanning, label printing* and photo tagging.

PrimeTest 100 PAT Testing Kits

The PrimeTest 100 PATBag Kit

This PAT testing kit includes:

  • PrimeTest 100 PAT Tester
  • Online PAT testing training course with exam
  • Durable, purpose-made PATBag with compartments for all of your PAT accessories and labels
  • 110V adaptor
  • 500 pass + 500 fail labels
  • Seaward Guide to PAT Testing
  • PAT reference look-up card
  • PAT logbook
  • Quick start video guide PAT Business builder CD-ROM and booklet

Part number: 345A925

Case Studies

Seaward helps voluntary organisation keep people safe Seaward helps voluntary organisation keep people safe
Seaward helps voluntary organisation keep people safe

When a volunteer-led organisation approached Seaward to see if it could help keep its customers safe, we were happy to help. We provided a PrimeTest PAT testing device to Bath Re...

Seaward shows support for youth charity Seaward shows support for youth charity
Seaward shows support for youth charity

A charity which helps vulnerable young people has been able to provide an extra service thanks to Seaward. We provided a PrimeTest PAT testing device to The Anchorage Trust, allo...


Request a Quote


Optional Accessories

Technical Specifications

Earth Continuity
Test Current+/- 200mA DC
Display Range0.00 – 19.99Ω
Pass Value0.2Ω
IEC Lead Test
Tests PerformedEarth continuity, Insulation resistance, Live, neutral continuity and polarity
Equivalent Leakage Class II
Test Voltage40V, 50Hz AC nominal
Display Range0.10 – 19.99mA
Pass Value0.25mA
Insulation Range
Test Voltages500VDC
Display Range0.20 – 19.99MΩ
Pass Value2MΩ
Equivalent Leakage Class I
Test Voltage40V, 50Hz AC nominal
Display Range0.10 – 19.99mA
Pass Value0.75mA
Power Socket Test
Input Voltage Range230V +10% - 15% AC
IndicatorsPhase to earth voltage, Phase to neutral voltage, Neutral earth
