KD1E/33D
109A911

KD1E/33D

Portable AC/DC indicator with digital display for use on systems up to 33kV

- AC/DC digital indicators
- Digital display
- Integral rechargeable battery


KD1E/33D

The KD1E/33D is a digital HV potential indicator which can be used to indicate the presence of voltage or make voltage measurements on earthed neutral systems up to 33kV.

The potential indicator display is powered by an integral rechargeable battery and is supplied complete with battery charger and PH3 proving unit in a bespoke carrying case. This robust, highly portable digital potential indicator is supplied with a carrying case for the indicator and accessories. These instruments provide a means of measuring voltage on earthed neutral electrical circuits.

Conforming in design lengths to recommended, creepage and safety standards, the KDIE series features high grade PVC tubing and incorporates totally encapsulated resistor chains. Supplied without Calibration Certificate when purchased online.


Request a Quote


Technical Specifications

Technical specification
Maximum system voltage33kV
Maximum voltage to earth19kV
Threshold voltage300V
Measuring range0.0kV-19.0k
Resolution100V
Accuracy+/- 5%
SensitivityAC/DC
Circuit current (IEC 61234-2)1.1mA nominal @19kV
Dielectric leakage current (IEC 61234-2)17uA nominal @ 40kV
Length (mm)600
Diameter (mm)25
Handle length (mm)235
Hand guard height (mm)23.5
Contact electrode typeDomed
